Applicable materials:River pebbles, calcite, quartz stone, marble, pebbles, bentonite, iron ore, bluestone, mountain stone, water slag, limestone, weathered sand, diabase, granite, basalt, etc.
Application scope:
Using a Chrome Ore Crushing Machine （double roller crusher） for chrome ore is efficient and economical. Huashengming’s crushers are robust, designed for medium- and low-hardness ores like chrome ore, limestone, and coal.
Firstly, the Chrome Ore Crushing Machine efficiently breaks down ore, delivering consistent particle size and reducing over-crushing. Additionally, it offers adjustable output, letting operators control particle size by setting the gap between rollers.
Moreover, its compact design ensures low energy consumption and easy maintenance, making it eco-friendly and durable for long-term use. Finally, the automatic hydraulic system protects the machine from unbreakable materials, enhancing safety and lifespan.
In chrome ore processing, the double roller crusher is a high-value option, fitting both primary and fine crushing needs in smelting and mining applications.
| Model | Roller diameter (mm) |
Roller length (mm) |
Max?feeding size (mm) |
Discharging size (mm) |
Capacity (t/h) |
Motor power (kw) |
Weight (kg) |
Dimension (L×W×H) |
| 450×500 | 450 | 500 | 200-500 | 15-100 | 30-60 | 7.5×2 | 3800 | 2260×2200×766 |
| 600×750 | 600 | 750 | 300-600 | 20-120 | 60-100 | 11×2 | 7200 | 2780×3065×1310 |
| 600×900 | 600 | 900 | 300-600 | 30-150 | 80-120 | 18.5×2 | 7800 | 4500×1900×1350 |
| 800×1050 | 800 | 1050 | 500-800 | 30-150 | 100-160 | 22×2 | 12600 | 2550×2050×1100 |
| 900×900 | 900 | 900 | 600-900 | 30-200 | 150-200 | 22×2 | 13500 | 2780×4100×1550 |
| 1015×760 | 1015 | 760 | 700-950 | 30-200 | 150-200 | 45×2 | 18800 | 7800×3200×1980 |
| 1200×1500 | 1200 | 1500 | 800-1050 | 30-200 | 200-300 | 55×2 | 52000 | 8010×4500×2050 |
