Applicable materials:Metal and nonmetal ores, cement, refractories, abrasives, glass raw materials, construction aggregate, artificial sand etc.
Application scope:Metal and nonmetal ores, cement, refractories, abrasives, glass raw materials, construction aggregate, artificial sand etc.
PCL sand making machine widely used in metal and nonmetal ores, cement, refractories, abrasives, glass raw materials, construction aggregate, artificial sand, and various metallurgical slag fine crushing and coarse grinding operations, particularly in the hard, extra hard and abrasive materials such as silicon carbide, silicon carbide, sintered bauxite, magnesia, etc., it is more advantageous than other types crushers.
| Model | Impeller?Speed (r/min) |
Best?Feeding?Size (mm) |
Capacity (t/h) |
Power (kw) |
Weight (t) |
Overall?Dimension (L×W×H)(mm) |
| PCL-600 | 2000-3000 | 30 | 12-30 | 2×30 | 5.6 | 2800×1550×2030 |
| PCL-750 | 1500-2500 | 35 | 25-55 | 2×45 | 7.3 | 3300×1800×2440 |
| PCL-900 | 1200-2000 | 40 | 55-100 | 2×(55-90) | 12.1 | 3750×2120×2660 |
| PCL-1050 | 1000-1700 | 45 | 100-160 | 2×(90-110) | 16.9 | 4480×2450×2906 |
| PCL-1250 | 850-1450 | 45 | 160-300 | 2×(132-185) | 22 | 4563×2650×3176 |
| PCL-1350 | 800-1193 | 50 | 200-360 | 2×(185-220) | 26 | 5340×2940×3650 |
